Naše mašine

01 Vertikalni obradni centri 5-OSA

Name

Manufacturer
Year

Technical characteristics

Navigation System

OKK VC-X350L
Vertical Machining Centers 5-Axis

OKK (Japan)
2014

20.000rpm, 80tools, X/Y/Z, 600/430/460mm, A -120-30deg, C Travel 360°, Turning option

FANUC 31-iB5

OKK VC-X500
Vertical Machining Centers 5-Axis

OKK (Japan)
2014

20.000rpm, 80tools, X/Y/Z600/430/460mm, A Axis -120-30deg, C Axis Travel 360°

FANUC 31-iB5

HERMLE C800U
Vertical Machining Centers 5-Axis

HERMLE (Germany)
1999

15.000rpm, 30tools, X800Y600Z500mm, B Axis360x 0.001°, C Axis:-20 to +90°

Heidenhain TNC 430

BROTHER M140 X1 + LANG ROBOTREX 52
Vertical Machining Centers 5-Axis

BROTHER (Japan)
2013

X:200mm Y:440mm Z:305mm, A:5～-95deg. C:360deg. S:12-16000rpm, BT-30; ATC-22, HP CTS unit

Brother CNC-C00

MATSUURA MAM72-25V APC
Vertical Machining Centers 5-Axis

MATSUURA (Japan)
2005

x-travel: 550 mm, y-travel: 410 mm, z-travel: 450 mm, B-axis (table): +-110 ° mm, c-axis: 360 °, table-size: 170 mm Ø, size of pallet: 130 mm Ø, table weight: 400 Kg, spindle speed: 15.000 rpm

FANUC 30iA

02 Vertikalni obradni centri 4-OSE

Name

Manufacturer
Year

Technical characteristics

Navigation System

QUASER MV154LX
Vertical Machining Centers 4-Axis

QUASER (Taiwan)
2006

12.000 rpm, 32 tools

FANUC 18iMB

QUASER MV154P/12
Vertical Machining Centers 4-Axis

QUASER (Taiwan)
2006

12.000 rpm, 24 tools

FANUC 18iMB

QUASER MV154P/12
Vertical Machining Centers 4-Axis

QUASER (Taiwan)
2006

12.000 rpm, 24 tools

FANUC 18iMB

HARDINGE VMC 600 II
Vertical Machining Centers 4-Axis

HARDINGE (USA)
2000

x:600 mm, y:512 mm, z:510 mm, spindle 8000rpm table:750x510 mm, 20 tools

FANUC 0M

03 Vertikalni obradni centri

Name

Manufacturer
Year

Technical characteristics

Navigation System

QUASER MK603SP/12 APC
Vertical Machine Center

QUASER (Taiwan)
2007

12.000 rpm, 48 tools, X 1020 mm, Y 610 mm, Z 610 mm, Table:1050x550 [mm]

FANUC 18iMB

FEELER QM‐32SA APC
Vertical Machine Center

FEELER (Taiwan)
2007

10.000 rpm, 24 tools, Twin Pallet Changer

FANUC Oi

QUASER MK603SE/12 APC
Vertical Machine Center

QUASER (Taiwan)
2006

12.000 rpm, 32 tools, X 1020 mm, Y 600 mm, Z 560 mm Table:1200x635 [mm]

FANUC 0iMC

QUASER MV204IIL/15
Vertical Machine Center

QUASER (Taiwan)
2004

15.000 rpm, 32 tools, X 1020 mm, Y 600 mm, Z 560 mm, Table:1200x635 [mm]

FANUC 18iM

QUASER MV204II/15
Vertical Machine Center

QUASER (Taiwan)
2003

15.000 rpm, 32 tools, X 1500 mm, Y 600 mm, Z 560 mm Table:1700x635 [mm]

FANUC 18iM

OKK VM-5 II
Vertical Machine Center

OKK (Japan)
2000

X820 Y510 Z510 [mm] table surface: 1050x560[mm] spindle speed: 14000[rpm] magazine:20 tools

FANUC 16iM

OKK PCV 40
Vertical Machine Center

OKK (Japan)
1985

X558 Y406 Z406mm Power 7.5 kW 6000 rpm #ATC30

FANUC 10M

04 Horizontalni obradni centri

Name

Manufacturer
Year

Technical characteristics

Navigation System

ENSHU JE80S APC
Horizontal Machine Center

ENSHU (Japan)
2006

15.000 rpm, 60 tools, Twin Pallet Changer

FANUC 18iM

QUASER MK603HP/10 APC
Horizontal Machine Center

QUASER (Taiwan)
2005

10.000 rpm, 60 tools, Twin Pallet Changer, Pallet load capacity:500kgs/each APC time : 8 seconds

FANUC 18iM

OKK HM40 APC
Horizontal Machine Center

OKK (Japan)
2001

10.000 rpm, 40 tools, Twin Pallet Changer

FANUC 16iM

TSUGAMI FMA3‐II APC
Horizontal Machine Center

TSUGAMI (Japan)
1997

10.000 rpm, 64 tools, 10 Pallet Changer

FANUC FS18

OKK HM40 APC
Horizontal Machine Center

OKK (Japan)
1995

10.000 rpm, 40 tools, Twin Pallet Changer

FANUC 18M

05 DRILL & TAP CENTER

Name

Manufacturer
Year

Technical characteristics

Navigation System

BROTHER R450 X1 APC + 4. Axis
Drill & Tap Center

BROTHER (Japan)
2014

T:600*300; S:450*320*305, S:12-16000rpm, BT-30; ATC-22, HP unit, 2x4.axis, APC

Brother CNC-C00

BROTHER TC-32BN QT APC + 4. Axis
Drill & Tap Center

BROTHER (Japan)
2013

T:600*300; S:550*400*415, S:12-16000rpm, BT-30;ATC-26, HP unit, 2x4.axis, APC

Brother CNC-B00

BROTHER TC-32BN QT APC + 4. Axis
Drill & Tap Center

BROTHER (Japan)
2007

T:600*300; S:550*400*415, S:12-16000rpm, BT-30;ATC-26, HP unit, 2x4.axis, APC

Brother CNC-B00

BROTHER TC-32BN QT APC
Drill & Tap Center

BROTHER (Japan)
2006

T:600*300; S:550*400*415, S:12-16000rpm, BT-30;ATC-26, HP unit, 2x4.axis, APC

Brother CNC-B00

BROTHER TC-22A 4. Axis
Drill & Tap Center

BROTHER (Japan)
1999

X700 mm, Y450 mm, Z410 mm, Spindle 8000 rpm, # ATC27, Taper BT-30, 4. AXIS

Brother CNC-A00

BROTHER TC-22A
Drill & Tap Center

BROTHER (Japan)
1999

X700 mm, Y450 mm, Z410 mm, Spindle 8000 rpm, # ATC27, Taper BT-30

Brother CNC-A00

ENSHU E130
Drill & Tap Center

ENSHU (Japan)
1999

X400 mm, Y300 mm, Z300 mm, RPM 10000 rpm, #ATC12 TaperBT30

YASNAC J50M

TAKISAWA MACV1‐E
Drill & Tap Center

TAKISAWA (Japan)
1989

WT 600x350mm, XYZ 430/350/465mm, 10 tools,6000rpm

FANUC 0M

06 LASER MARKER MAŠINE

Name

Manufacturer
Year

Technical characteristics

Navigation System

TRUMPF TruMark 5020
Laser Marker Machine

TRUMPF (Germany)
2016

Max. size of marking field[1] 290 x 290 mm²; f = 420 mm, Scanner accuracy ±50 µm

BAUBLYS BL150S
Laser Marker Machine

BAUBLYS (Germany)
2001

laser wave length 1064mm, YAG power:150W, impulse time: CW/50ns

07 MAŠINE ZA SEČENJE ŽICE EDM

Name

Manufacturer
Year

Technical characteristics

Navigation System

FANUC ROBOCUT α-C600iA
Wire-cut EDM

FANUC (Japan)
2014

Wire diameter, [mm] φ0.1 - 0.3, XY axis 600x400, UV axis, 200 x 200, Z axis 310

Fanuc 31i-W

FANUC ROBOCUT α-0iA
Wire-cut EDM

FANUC (Japan)
1999

travels: x320mm, y220mm, z255mm, tank size:770 x 560 x 410mm

Fanuc 18i-W

FANUC ROBOCUT α-1iA
Wire-cut EDM

FANUC (Japan)
1999

travels: x320mm, y220mm, z255mm tank size:770 x 560 x 410mm

Fanuc 18i-W

08 MAŠINE ZA KOORDINATNO MERENJE CMM

Name

Manufacturer
Year

Technical characteristics

Navigation System

MITUTOYO STRATO‐APEX 9166
Coordinate Measuring Machine CMM

MITUTOYO (Japan)
2011

Travel: X‐900mm, Y‐1600mm, Z‐ 600mm

MITUTOYO EURO‐C‐A574
Coordinate Measuring Machine CMM

MITUTOYO (Japan)
2001

Travel: X‐505mm, Y‐705mm, Z‐ 405mm

GOM ATOS II - Optical 3D scanner
Coordinate Measuring Machine CMM

GOM (Germany)
2016

Travel: X‐900mm, Y‐1600mm, Z‐ 600mm

09 CNC STRUGOVI

Name

Manufacturer
Year

Technical characteristics

Navigation System

YCM GT300MA
CNC Lathes

YCM (Taiwan)
2007

3.000 rpm, 12 tools, Power tools

FANUC 0i-TC

HYUNDAI KIA SKT 21L
CNC Lathes

HYUNDAI KIA (South Korea)
2006

4000rpm, 12 tools, Max boring bar ɸ51

FANUC 21i-TB

HYUNDAI KIA SKT 21L
CNC Lathes

HYUNDAI KIA (South Korea)
2006

4000rpm, 12 tools, Max boring bar ɸ51

FANUC 21i-TB

HYUNDAI KIA SKT 21
CNC Lathes

HYUNDAI KIA (South Korea)
2005

4000rpm, 12 tools, Max boring bar ɸ51

FANUC 0i-TC

DOOSAN S‐550L
CNC Lathes

MECATEC Co. (Korea)
2002

2.500 rpm,12 tools Max boring bar ɸ102

FANUC 21iTB

HARDINGE CONQUEST T42
CNC Lathes

HARDINGE (USA)
1995

4.000 rpm, 12 tools, Max boring bar ɸ42 BF

FANUC 18T

IKEGAI TUR‐15
CNC Lathes

IKEGAI (Japan)
1995

4.000 rpm, 12 tools Max boring bar ɸ42 BF, Power Tools

FANUC 0T

DAEWOO Ecoturn 250HC
CNC Lathes

DAEWOO (Korea)
1993

4.000 rpm, 10 tools, Max boring bar ɸ70

FANUC 0T

TAKISAWA TC-3
CNC Lathes

TAKISAWA (Japan)
1991

X 300,Z 600mm, 10 tools, 4000rpm

FANUC 15 T

DYNA Myte 3300
CNC Lathes

DYNA M. (Taiwan)
1982

4.500 rpm,8 tools, Max boring bar ɸ38

MITSUBISHI MELDAS L3

10 CNC AUTOMATSKI STRUGOVI SWISS-TIP

Name

Manufacturer
Year

Technical characteristics

Navigation System

STAR ST-38
CNC Swiss-type Automatic Lathe

STAR (Japan)
2012

Dia.22mm,7Axis,19 tools I 10000rpm II 7000rpm Lmax=150mm

FANUC 30i model A

STAR SR‐32J
CNC Swiss-type Automatic Lathe

STAR (Japan)
2011

Dia.32mm,7Axis,I 7000rpm II 5000rpm Lmax=250mm

Fanuc 18i‐TB

STAR SR-20J TYPE C
CNC Swiss-type Automatic Lathe

STAR (Japan)
2010

Dia.22mm,7Axis,19 tools I 10000rpm II 7000rpm Lmax=150mm

Fanuc 18i‐TB

TORNOS Deco Sigma 8
CNC Swiss-type Automatic Lathe

TORNOS (Switzerland)
2007

4.000 rpm,10 tools Max boring bar ɸ10, + BF 20tools, Lmax 17mm, 5 axis

FANUC 32i MODEL A

TORNOS Deco 13a
CNC Swiss-type Automatic Lathe

TORNOS (Switzerland)
2002

Max boring bar ɸ17, + BF 20 tools, Lmax 90mm, 10 axis, 2 Spindle

FANUC 18i

TORNOS ENC-264
CNC Swiss-type Automatic Lathe

TORNOS (Switzerland)
1996

min/max bar dia 4/26mm, turning length max 275mm, spindle 6000 RPM, 2 driven tools (1x radial,1x axial) barloader 4000mm

FANUC OTT

11 CNC VIŠENAMENSKI OBRADNI CENTRI

Name

Manufacturer
Year

Technical characteristics

Navigation System

NAKAMURA TOME NTY3-250
CNC Swiss-type Automatic Lathe

NAKAMURA TOME (Japan)
2015

Max. turning diameter 225mm. Distance between spindle nosemax.1200mm/min.255mm 3 Turret C-Axis, Driven Tools, Parts Catcher

FANUC 31i

NAKAMURA TOME WT-150
CNC Swiss-type Automatic Lathe

NAKAMURA TOME (Japan)
2008

Turning Dia 170mm; Turning Length 400mm; Travel,X167,Z465,Y+/- 35 mm,2 spindel, 2turrets; tools 12/12; C-Axis, Driven Tools, Parts Catcher

FANUC 18i TB

TAKISAWA TMM-250
CNC Swiss-type Automatic Lathe

TAKISAWA (Japan)
2003

4.000 rpm,2x15 tools, 2x c-axe,Y axis

FANUC 21i

NAKAMURA TOME WT-150 II
CNC Swiss-type Automatic Lathe

NAKAMURA TOME (Japan)
2013

Turning Dia 190mm; Turning Length 515mm; Travel X 167/192; Z 700/700; Y +50/-42; W 940 mm, 2 spindle - 6000 rpm, 2 turrets; Tool Station 12/12; C-Axis, Driven Tools, Parts Catcher, LNS Barfeeder, Robot unloader arm.

FANUC 31i Model B

OKUMA Twin star LT200 My
CNC Swiss-type Automatic Lathe

OKUMA (Japan)
2008

Turning Dia 210mm; Turning Length 515mm; Travel X167;Z465;Y+/-35 mm, 2 spindle - 5000 rpm, 2 turrets; Tool Station 12/12; 48 index position C-Axis, Driven Tools 12x2, Parts Catcher, LNS Barfeeder

OSP-P200L

OKUMA LT3000 EX
CNC Swiss-type Automatic Lathe

OKUMA (Japan)
2015

3 turrets, 3 Y-axis, 2 spindles Max. turning diameter 350 mm Big bore 91 mm Parts catcher left and right spindle Coolant th. spindle, 15 bar coolant th. spindle barfeeder LNS Move S2 ,

OSP-P200L

NAKAMURA TOME SUPER NTJ
CNC Swiss-type Automatic Lathe

NAKAMURA TOME (Japan)
2008

Bar diameter: 65 mm - Max turning diameter: 190 mm SUB SPINDLE - Bar diameter: 51 mm - Spindle power: 11 kW - Spindle speed: 5000 rpm Axis strokes: X=345 mm - Y=+/- 45 mm - Z=1240 mm B axis stroke: +/- 91°

FANUC 18i TB
